Compatible with ZX110 ZX120 ZX125 ZX135 9196343 Swing Device Used For Hitachi Excavator Swing Drive System

Parts No.: 9196343 Excavator Model: ZX120 Excavator Brand: Hitachi Packing: Wood Box Warranty: 3/6 Months Weight: 120 KG High Light: swing reduction gear, swing gear box ZX110 ZX120 ZX125 ZX135 9196343 Swing Device Used For Hitachi Excavator Swing Drive System

Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.

Spec Sheet

Excavator spare parts name Swing reducer Equipment Model EC55 Parts Category excavator swing gear Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Application

ZX110 . ZX110-E . ZX110M . ZX120 . ZX120-E . ZX120-HCMC . ZX125US . ZX125US-E . ZX130-AMS . ZX130-HCME . ZX130H . ZX130K . ZX130W . ZX130W-AMS . ZX135US . ZX135US-E . ZX135US-HCME . ZX135USK . ZX135UST . Hitachi

Parts Diagram

ENTIRE GROUP SWING DEVICE:00.2044629[1] -
SHAFT;PROP.
01.3083710[1] -
SLEEVE
02.A811095[1] -
O-RING
03.4430041[1] -
BRG.;ROL.
04.4411143[1] -
SEAL;OIL
05.1027901[1] -
HOUSING
06.4408119[1] -
BRG.;ROL.
07.3083674[1] -
NUT
08.4407745[1] -
PLATE;LOCK
10.J901020[2] -
BOLT
11.2042965[1] -
CARRIER
12.4176070[1] -
PLATE;THRUST
13.4408102[3] -
PIN
14.4414855[3] -
BRG.;NEEDLE
15.3084940[3] -
GEAR;PLANETARY
16.4414833[6] -
PLATE;THRUST
17.4116308[6] -
PIN;SPRING
19.3092035[1] -
GEAR;SUN
20.2045146[1] -
GEAR;RING
21.M341440[12] -
BOLT;SOCKET
23.2042964[1] -
CARRIER
24.4244904[1] -
PLATE;THRUST
25.4408122[3] -
PIN
26.4430040[3] -
BRG.;NEEDLE
27.3083741[3] -
GEAR;PLANETARY
28.4408002[3] -
PLATE;THRUST
29.3083740[1] -
GEAR;SUN
31.3087949[1] -
PIPE
33.94-2012[1] -
PLUG
61.8082514[1] -
COVER (for transportation)
62.J011040[7] -
BOLT;SEMS
62.J271040 T[7] -
BOLT;SEMS J901040
62.J271040 T[7] -
BOLT;SEMS J222010 (for transportation)
64.94-2011[1] -
PLUG (for transportation)
65.3053093[1] -
NAME-PLATE (for transportation)
66.M492564[2] -
SCREW;DRIVE (for transportation)
101.9182929 I[1] -
MOTOR;OIL 9196962 (for assembly of machine)
101.9196962[1] -
MOTOR;OIL (for transportation)
102.927488[1] -
RING;RETAINING
106.4298608[1] -
CAP
107.M341025[7] -
BOLT;SOCKET
108.3053093[1] -
NAME-PLATE
109.M492564[2] -
SCREW;DRIVE
114.4449144[1] -
PIPE
115.3090862[1] -
GAUGE;LEVEL
116.4449182[1] -
PIPE
117.4436535[1] -
SENSOR;PRES.
200.9196343[1] -
SWING DEVICE (WITHOUT MOTOR)
