Compatible with XKAQ-00399 XKAQ-00188 XKAQ-00969 Carrier Assy No.2 For Hyundai R305LC-7 Excavator Final Drive

Product Name: Carrier Assy No.2 Excavator Model: R305LC-7 Parts Number: XKAQ-00399 XKAQ-00188 XKAQ-00969 Warranty: 6 Months Category: Excavator Final Drive Packing: Standard Wooden Box High Light: cat final drive, excavator gearbox

XKAQ-00399 XKAQ-00188 XKAQ-00969 Carrier Assy No.2 Used For Hyundai R305LC-7 Excavator Final Drive

Spec Sheet

Excavator spare parts name Carrier assy no.2 Equipment Model R305LC-7 Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Application

7-SERIES CRAWLER EXCAVATOR R250LC7 R250LC7A R290LC7 R290LC7A R300LC7 R305LC7 R320LC7 R320LC7A
9-SERIES CRAWLER EXCAVATOR R250LC9 R290LC9 R320LC9 Hyundai

Parts Diagram

Pos. Part No Qty Parts name Comments *-2. 31N8-40070BG [1] T/REDUCTION GEAR *-2. 31N8-40071BG [1] T/REDUCTION GEAR *-2. 31N8-40072 [1] T/REDUCTION GEAR *-2. 31N8-40073 [1] T/REDUCTION GEAR 2 XKAQ-00173 [1] SEAL-FLOATING 2 XKAQ-00803 [1] SEAL-FLOATING 3 XKAQ-00174 [1] HOUSING 3 XKAQ-00802 [1] HOUSING 4 XKAQ-00175 [2] BEARING-ANGULAR 4 XKAQ-00175-AS [2] BEARING-ANGULAR FOR AS ONLY 5 XKAQ-00176 [1] SHIM 6 XKAQ-00177 [1] RETAINER 7 XKAQ-00178 [17] BOLT-WRENCH 8 XKAQ-00179 [1] CARRIER ASSY-NO.3 8 XKAQ-00398 [1] CARRIER 3 ASSY 8-1. XKAQ-00180 [1] CARRIER-NO.3 8-1. XKAQ-00396 [1] CARRIER 3 8-2. XKAQ-00181 [4] GEAR-PLANETARY NO.3 8-2. XKAQ-00389 [4] GEAR 3-PLANETARY 8-3. XKAQ-00182 [72] NEEDLE-NO.3 8-3. XKAQ-00390 [72] NEEDLE 3 8-4. XKAQ-00183 [8] WASHER-THRUST NO.3 8-4. XKAQ-00391 [8] WASHER 3-THRUST 8-5. XKAQ-00184 [4] PIN 3 8-6. XKAQ-00185 [4] PIN 3-SPRING 8-7. XKAQ-00186 [1] GEAR 3-SUN 8-8. XKAQ-00187 [1] RING 3-SNAP 8-9. XKAQ-00651 [4] PIN 3-SPRING 9 XKAQ-00188 [1] CARRIER ASSY-NO.2 9 XKAQ-00399 [1] CARRIER ASSY 2 9-1. XKAQ-00189 [1] CARRIER-NO.2 9-1. XKAQ-00397 [1] CARRIER 2 9-2. XKAQ-00190 [3] GEAR-PLANETARY NO.2 9-2. XKAQ-00392 [3] GEAR-PLANETERY 2 9-3. XKAQ-00191 [45] NEEDLE-NO.2 9-3. XKAQ-00393 [45] NEEDLE 2 9-4. XKAQ-00192 [6] WASHER-THRUST NO.2 9-4. XKAQ-00394 [6] WASHER-THRUST 2 9-5. XKAQ-00193 [3] PIN 2 9-6. XKAQ-00194 [6] PIN 2-SPRING 9-7. XKAQ-00195 [1] GEAR 2-SUN 9-8. XKAQ-00196 [1] RING 2-SNAP 9-9. XKAQ-00650 [6] PIN 2-SRPING 10 XKAQ-00197 [1] CARRIER ASSY-NO.1 10 XKAQ-00400 [1] CARRIER 1 ASSY 10-1. XKAQ-00198 [1] CARRIER 1 10-2. XKAQ-00199 [3] GEAR 1-PLANETARY 10-3. XKAQ-00200 [3] BEARING-NEEDLE 10-4. XKAQ-00201 [6] WASHER-THRUST NO.1 10-4. XKAQ-00395 [6] WASHER 1-THRUST 10-5. XKAQ-00202 [3] PIN 1 11 XKAQ-00203 [1] GEAR 1-SUN 12 XKAQ-00204 [3] PLUG 13 XKAQ-00205 [4] PIN-LOCK 14 XKAQ-00206 [1] GEAR-RING 14 XKAQ-00762 [1] GEAR-RING 15 XKAQ-00207 [24] BOLT-WRENCH 16 XKAQ-00208 [1] RING-THRUST 17 XKAQ-00209 [1] COVER 18 XKAQ-00210 [1] RING 2-THRUST 19 XKAQ-00211 [16] BOLT-WRENCH 20 XKAQ-00212 [1] MOTOR-RING 21 XKAQ-00213 [1] RING 3-THRUST 22 XKAQ-00214 [1] PAD 23 XKAQ-00215 [1] COUPLING N. @ [1] NOT SUPPLIED PARTS
Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.
Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with XKAQ-00399 XKAQ-00188 XKAQ-00969 Carrier Assy No.2 For Hyundai R305LC-7 Excavator Final Drive provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
