Compatible with VOE14569767 14569767 VOE14724044 14724044 EC290B EC290C EC300D Excavator Swing Gearbox EC290B EC300D

Category: Excavator Swing Gear Parts Machine Model: EC290B EC300D Parts NO.: VOE14569767 VOE14724044 Material: Forged, Steel Warranty: 3/6 Months Package: Standard Export Carton High Light: swing gear box, swing reduction gear VOE14569767 14569767 VOE14724044 14724044 EC290B EC290C EC300D Excavator Swing Gearbox

Spec Sheet

Excavator spare parts name Swing device gearbox Equipment Model EC290B EC300D Parts Category Excavator Swing gear Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Application

EC290B EC290C EC300D EC300E FC3329C Volvo.Heavy

Parts Diagram

Pos. Part No Qty Parts name Comments VOE14569767 [1] Swing gearbox S/N -19948/-35895/-50154 /-86284 VOE14724044 [1] Swing gearbox S/N 19949- 1 VOE14547262 [1] Case 2 VOE14547260 [1] Ring 3 VOE14547259 [1] Collar 4 VOE14547258 [1] Shaft 5 VOE14547263 [1] Cover 6 VOE14547266 [1] Gear 7 VOE997902 [20] Hex. socket screw 8 VOE997876 [12] Hex. socket screw 9 VOE14547261 [1] Bearing 10 VOE14883861 [1] Plug 11 VOE914167 [1] Lubricating nipple 12 VOE14566830 [1] Seal 13 VOE14547265 [1] Bearing 14 SA9541-01110 [1] Retaining ring 15 SA7118-30380 [1] Thrust ring 16 VOE14547272 [1] Gear 17 VOE14880960 [1] Retaining ring 18 VOE14547279 [1] Gear 19 VOE14547278 [1] Thrust washer 20 VOE14547281 [1] Pipe 21 VOE14547280 [1] Planet carrier 22 VOE14547267 [1] Planet carrier 23 VOE14547271 [4] Pin 24 VOE14547268 [4] Gear 25 VOE14547269 [4] Bushing 26 VOE14556491 [8] Washer 27 SA9325-06012 [4] Spring pin 28 VOE14547273 [1] Planet carrier 29 VOE14547274 [1] Planet carrier 30 VOE14547275 [3] Gear 31 SA7117-30230 [3] Needle bearing 32 VOE14547277 [3] Pin 33 SA9325-06012 [3] Spring pin 34 VOE14547276 [6] Washer 35 VOE950677 [4] Pin 36 VOE949329 [1] Gasket 37 VOE14722461 [1] Draining valve

Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with VOE14569767 14569767 VOE14724044 14724044 EC290B EC290C EC300D Excavator Swing Gearbox EC290B EC300D provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
