Product Name: Planet Gear Excavator Model: EC360B EC300D EC380D Parts Number: 14566428 Warranty: 6 Months Category: Excavator Final Drive Packing: Standard Wooden Box High Light: cat final drive, excavator gearbox
VOE14566428 14566428 Planetary Gear Used For
Volvo EC360B EC300D EC380D Excavator Final Drive Parts
Spec Sheet
Excavator spare parts name planetary gear Equipment Model EC300D EC360B EC380 Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days
Application
EC290C EC300D EC300E EC330B EC330C EC340D EC350D EC350E EC360B EC360C EC360CHR EC380D EC380DHR EC380E EC380EHR ECR305C FC3329C PL3005D Volvo.Heavy
Parts Diagram
Pos. Part No Qty Parts name Comments VOE14566401 [1] Transfer gearbox 1 VOE14566402 [1] Housing 2 VOE14566409 [1] Gear 3 SA7117-38230 [2] Bearing 4 VOE14566404 [1] Shim 5 VOE14566403 [1] Retainer 6 VOE14566410 [1] Planet carrier 7 VOE14566411 [1] Planet carrier 8 VOE14566415 [4] Pin 9 VOE14566413 [4] Planetary gear 10 VOE14566414 [8] Washer 11 SA9325-06012 [4] Spring pin 12 SA8230-21020 [1] Thrust ring 13 VOE14566412 [4] Needle bearing 14 VOE984088 [20] Hex. socket screw 15 VOE14566416 [1] Gear 16 VOE14566418 [1] Planet carrier 17 VOE14566423 [3] Pin 18 VOE14566419 [1] Planet carrier 19 VOE14566421 [3] Planetary gear 20 VOE14566422 [6] Washer 21 SA9325-06012 [3] Spring pin 22 VOE14566420 [3] Needle bearing 23 VOE14566433 [1] Thrust washer 24 VOE14566424 [1] Gear 25 VOE14566425 [1] Planet carrier 26 VOE14566426 [1] Planet carrier 27 VOE14566428 [3] Planetary gear 28 VOE14566429 [6] Washer 29 VOE14566430 [3] Pin 30 SA9325-06012 [3] Spring pin 31 VOE14566427 [3] Needle bearing 32 VOE14569232 [1] Ring 33 VOE14566417 [1] Ring 34 VOE14566431 [1] Gear 35 VOE914467 [1] Retaining ring 36 VOE14566432 [1] Cover 37 VOE60110006 [18] Hexagon screw 38 SA9213-20000 [18] Spring washer 39 VOE14883847 [2] Plug 40 VOE990557 [2] O-ring 41 VOE950677 [4] Pin 42 VOE14667679 [1] Seal
Description
The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.
Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.
This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with VOE14566428 14566428 Planetary Gear For Volvo EC360B EC300D EC380D Excavator Final Drive Parts provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
