Compatible with VOE14528260 14528260 VOE14566401 14566401 Excavator Final Drive Used For Volvo EC360B EC330B Travel Gearbox

Parts No.: VOE14528260 VOE14566401 Excavator Model: EC360 Excavator Brand: Volvo Packing: Wood Box Warranty: 6 Months Weight: 350 KG High Light: final drive parts, cat final drive VOE14528260 14528260 VOE14566401 14566401 Excavator Final Drive Used For Volvo EC360B EC330B Travel Gearbox

Spec Sheet

Excavator spare parts name Travel reduction gear Equipment Model EC290B EC330B EC330C EC360B EC360C EC380D Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Product photos

Parts Diagram VOE14528258[1]-
Travel Gearbox
1.SA7117-38221[1]-
Housing SER NO 10001-10928
VOE14521858[1]-
Housing SER NO 10929-11467
VOE14522896[1]-
Housing SER NO 11468-
2.SA7117-38230[2]-
Bearing
3.SA7117-38240[1]-
Seal SER NO 10001-11467
VOE14522998[1]-
Sealing SER NO 11468-
4.SA7117-38251[1]-
Nut SER NO 10001-12345
VOE14528319[1]-
Nut SER NO 12346-
5.SA1036-00300[1]-
Ring
6.SA7117-38271[4]-
Planet gear
7.SA7117-38520[4]-
Needle bearing
8.SA7117-38301[4]-
Pin
9.SA7117-38311[1]-
Gear SER NO 10001-11311
VOE14522897[1]-
Gear SER NO 11312-
10.SA9016-21620[20]-
Hex. socket screw
11.SA7117-38210[1]-
Carrier
12.SA7117-34320[6]-
Washer
13.SA7117-38320[1]-
Planet carrier
14.SA7117-38330[1]-
Gear
15.SA7117-38340[1]-
Ring
16.SA7117-38350[3]-
Planetary Gear
17.SA7117-38360[3]-
Needle bearing
18.SA7117-38380[1]-
Pin
19.SA9325-06012[3]-
Spring pin
20.SA1036-00290[1]-
Thrust ring
21.SA7117-38371[1]-
Gear
22.VOE14551156[1]-
Planet carrier
23.SA7117-38180[1]-
Pin
24.SA7117-38391[1]-
Planet carrier
25.SA7117-38400[1]-
Gear
26.SA7117-38410[1]-
Ring
27.SA7117-38420[3]-
Needle Bearing
28. [3]-
Planetary Gear
29.VOE14556489[1]-
Washer
30.VOE14556490[1]-
Washer
31.SA9325-06012[3]-
Spring pin
32.SA9541-01040[3]-
Ring
33.VOE914467[1]-
Retaining ring
34.SA7117-38190[1]-
Cover SER NO 10001-10255
VOE14517931[1]-
Cover SER NO 10256-11311
VOE14601855[1]-
Cover SER NO 11312-
35.VOE967631[16]-
Hex. socket screw SER NO 10001-11311
VOE983252[16]-
Hexagon screw SER NO 11312-
36.SA9415-43042[3]-
Plug SER NO 10001-10255
SA9415-11052[3]-
Plug SER NO 10256-
37.SA7117-38460[4]-
Inner ring
38.SA7117-38470[8]-
Washer
39.SA9023-10803[2]-
Set screw SER NO 10001-12345
VOE14526459[2]-
Screw SER NO 12346-
40.SA1146-06870[2]-
Pad SER NO 10001-12345
41.SA9325-06012[4]-
Spring pin
42.SA9511-12024[3]-
O-ring SER NO 10256-
43.VOE955922[16]-
Spring washer SER NO 11312

ENTIRE GROUP Travel gearbox:

[1]- VOE14528260
Gearbox
1.VOE14522996[1]-
Housing .
2.SA7117-38230[2]-
Bearing .
3.VOE14522998[1]-
Seal .
4.VOE14528319[1]-
Nut .
5.SA7117-38271[4]-
Planet gear .
6.SA7117-38520[4]-
Needle bearing .
7.SA7117-38301[4]-
Pin .
8.VOE14522997[1]-
Gear .
9.SA9016-21620[24]-
Hex. socket screw .
10.SA1036-00290[1]-
Thrust ring .
11.SA7117-38210[1]-
Carrier .
12.SA7117-34320[6]-
Washer .
13.SA7117-38320[1]-
Planet carrier .
14.SA7117-38330[1]-
Gear .
15.SA7117-38340[1]-
Ring .
16.SA7117-38350[3]-
Planetary Gear .
17.SA7117-38360[3]-
Needle bearing .
18.SA7117-38380[3]-
Pin .
19.SA9325-06012[3]-
Spring pin .
20.VOE14551152[1]-
Planet gear .
VOE14515055[1]-
Carrier .
21.SA7117-38180[3]-
Pin .
22.SA7117-38400[1]-
Gear .
23.SA7117-38410[1]-
Ring .
24.VOE14556490[3]-
Washer .
25.SA7117-38420[3]-
Needle Bearing .
26.VOE14556489[3]-
Washer .
27.SA9541-01040[3]-
Retaining ring .
28.SA9325-06012[3]-
Spring pin .
29.VOE14513559[3]-
Planetary Gear .
30.VOE14601855[1]-
Cover .
31.VOE983252[16]-
Hexagon screw
32.SA9415-11052[3]-
Plug .
33.SA7117-38460[4]-
Inner ring .
34.SA7117-38470[8]-
Washer .
35.VOE14526459[3]-
Screw .
36.VOE983524[3]-
O-ring .
37.SA9325-06012[4]-
Spring pin .
38.VOE14515056[1]-
Sun gear .
39.VOE914467[1]-
Retaining ring .
40.VOE955922[16]-
Spring washer
41.SA1036-00300[1]-
Ring

Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.

Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with VOE14528260 14528260 VOE14566401 14566401 Excavator Final Drive Used For Volvo EC360B EC330B Travel Gearbox provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
