Compatible with SA7118-38100 VOE14542165 VOE14569767 Swing Gearbox Used For Volvo EC290B EC290C EC300D

Parts No.: SA7118-38100 VOE14542165 VOE14569767 Excavator Model: EC290B EC290C EC300D Excavator Brand: Volvo Packing: Wood Box Warranty: 3/6 Months Weight: 350KG High Light: swing gear box, swing bearing SA7118-38100 VOE14542165 VOE14569767 Swing Gearbox Used For Volvo EC290B EC290C EC300D

Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.

Spec Sheet

Excavator spare parts name Swing reducer Equipment Model EC290 EC300 Parts Category excavator swing gear Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Parts Diagram

ENTIRE GROUP Swing gearbox:

VOE14569767[1]-
Swing gearbox .
1.VOE14547262[1]-
Case .
2.VOE14547260[1]-
Ring .
3.VOE14547259[1]-
Collar .
4.VOE14547258[1]-
Shaft .
5.VOE14547263[1]-
Cover .
6.VOE14547266[1]-
Gear .
7.VOE984363[0020]-
Hex. socket screw .
8.VOE13944938[12]-
Screw .
9.VOE14547261[1]-
Bearing .
10.SA9415-43012[1]-
Plug .
11.VOE914167[1]-
Lubricating nipple .
12.VOE14566830[1]-
Seal .
13.VOE14547265[1]-
Bearing .
14.SA9541-01110[1]-
Retaining ring .
15.SA7118-30380[1]-
Thrust ring .
16.VOE14547272[1]-
Gear .
17.VOE14880960[1]-
Retaining ring .
18.VOE14547279[1]-
Gear .
19.VOE14547278[1]-
Thrust washer .
20.VOE14547281[1]-
Pipe .
21.VOE14547280[1]-
Planet carrier .
22.VOE14547267[1]-
Planet carrier .
23.VOE14547271[4]-
Pin .
24.VOE14547268[4]-
Gear .
25.VOE14547269[4]-
Bushing .
26.VOE14556491[8]-
Washer .
27.SA9325-06012[4]-
Spring pin .
28.VOE14547273[1]-
Planet carrier .
29.VOE14547274[1]-
Planet carrier .
30.VOE14547275[3]-
Gear .
31.SA7117-30230[3]-
Needle bearing .
32.VOE14547277[3]-
Pin .
33.SA9325-06012[3]-
Spring pin .
34.VOE14547276[6]-
Washer .
35.VOE950677[4]-
Pin .
36.VOE949329[1]-
Gasket .
37.VOE14521728[1]-
Valve

ENTIRE GROUP Swing gearbox:

VOE14542165[1]-
Swing gearbox .
1.VOE14521728[1]-
Valve .
2.SA1036-00590[1]-
Sun gear NO 1 .
3.SA1036-00750[12]-
Bolt SER NO 10001-11003 .
VOE984368[12]-
Hex. socket screw SER NO 11004- .
4.VOE14518702[1]-
Carrier NO 2,SER NO 10320- .
5.SA1036-00630[1]-
Knob .
6.VOE14504158[1]-
Crankshaft .
7.VOE14504159[1]-
Bearing .
8.VOE14504160[1]-
Bearing .
9.VOE14510173[3]-
Pin .
10.SA7118-45221[3]-
Planetary Gear .
11.SA7118-45260[6]-
Washer .
12.SA9325-10012[3]-
Spring pin .
13.VOE14504164[1]-
Sun gear NO 2 .
14.SA7118-34480[1]-
Washer .
15.SA7118-38400[1]-
Planet carrier NO 1 .
16.SA7117-30230[3]-
Needle bearing .
17.SA7118-38410[1]-
Planet carrier .
18.SA7118-38420[3]-
Planetary Gear .
19.SA7118-38430[3]-
Pin .
20.SA7118-38450[6]-
Washer .
21.SA9325-08010[3]-
Spring pin .
22.VOE914470[3]-
Snap ring .
23.VOE14504161[1]-
Casing .
24.VOE14504162[1]-
Seal .
25. [1]-
Casing
26.VOE14540733[1]-
Pipe .
27.SA7118-38460[1]-
Gear NO 1 .
28. [1]-
Gear NO 2
29.SA7118-45380[4]-
Pin .
30.SA9016-21820[16]-
Bolt SER NO 10001-11003 .
VOE984370[16]-
Hex. socket screw SER NO 11312- .
31.SA9426-20090[1]-
Gasket .
32.SA9541-01085[1]-
Retaining ring .
10.VOE14526227[1]-
Overhaul kit .
20.VOE14553108[1]-
Housing inc 25,28,29

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with SA7118-38100 VOE14542165 VOE14569767 Swing Gearbox Used For Volvo EC290B EC290C EC300D provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
