SA7118-30100 VOE14541069 Excavator Swing Gearbox Used For Volvo EC210B EC210 EC235C EC220D
Shop Premium SA7118-30100 VOE14541069 Excavator Swing Gearbox Used For Volvo EC210B EC210 EC235C EC220D - EC210 and Enjoy Fast Delivery! Choose quality components for performance and control. Order now!
Fast delivery to your door, with a 2-Year Warranty and a 90-day return policy.
| Parts No.: | SA7118-30100 VOE14541069 | Excavator Model: | EC210B |
|---|---|---|---|
| Excavator Brand: | Volvo | Packing: | Wood Box |
| Warranty: | 3/6 Months | Weight: | 180KG |
| High Light: | swing gear box,swing bearing | ||
- Swing Reduction Gearbox SA7118-30100 VOE14541069 Fit For Volvo EC210B EC210C EC235C EC220D EC200B
- Description
The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.
Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.
- Spec Sheet
| Excavator spare parts name | Swing reducer |
| Equipment Model | EC210 EC210B EC210C EC235 EC220D |
| Parts Category | excavator swing gear |
| Spare parts Condition | Brand new |
| MOQ of order(PCS, SET) | 1 |
| Parts Availability | In stock |
| Delivery Lead time | 1-3 days |
- Parts Diagram
ENTIRE GROUP Swing gearbox:
VOE14541069[1]-Swing gearbox
1.VOE14528929[1]-
Shaft
2.VOE14540405[1]-
Collar
3.VOE14509281[1]-
Cover
4.VOE990596[1]-
O-ring
5.VOE14508911[1]-
Sealing
6.SA9011-11007[10]-
Bolt
7.SA7118-01740[1]-
Roller bearing
8.SA7118-00040[1]-
Roller bearing
9.SA9541-01090[1]-
Retaining ring
10.SA9324-21617[4]-
Pin
11.VOE984363[12]-
Hex. socket screw
12.SA7118-30370[1]-
Plate
13.SA7118-30380[1]-
Thrust ring
14.SA7118-30390[1]-
Gear
15.SA7118-30480[1]-
Washer
16.SA7118-30490[1]-
Sun gear
17.VOE14540733[1]-
Pipe
18.VOE14521728[1]-
Valve
19.SA9426-20090[1]-
Gasket
20.SA7118-30200[1]-
Planet carrier No.2
21.SA7118-30210[1]-
Planet carrier
22.SA7118-30220[3]-
Planetary Gear
23.SA7118-30230[3]-
Pin
24.SA7118-30260[6]-
Washer
25.SA9325-08010[3]-
Spring pin
26.VOE14528725[1]-
Planet carrier No.1
27.SA7118-30410[1]-
Planet carrier
28.SA7118-30420[3]-
Planetary gear
29.VOE14528726[3]-
Pin
30.VOE14550879[3]-
Needle bearing
31.SA7118-30450[3]-
Washer
32.SA7118-30460[3]-
Washer
33.SA9541-01042[3]-
Ring
34.SA9325-08010[3]-
Spring pin
35.SA7118-30350[1]-
Ring gear
36.SA7118-30340[1]-
Case
10.VOE14526214[1]-
Overhaul kit
| OEM NO. | EC210 |
|---|
