Compatible with KRA1274 160142A1 LNM0389 Final Drive Reduction Gear Used For CX210B 9030B SH200 CX240 SH200 CX210 9030B

Parts No.: KRA1274 160142A1 LNM0389 Excavator Model: SH200 CX210 Excavator Brand: Sumitomo Packing: Wood Box Warranty: 3/6 Months Weight: 360KG High Light: final drive parts, excavator gearbox KRA1274 160142A1 LNM0389 Final Drive Reduction Gear Used For CX210B 9030B SH200 CX240

Spec Sheet

Excavator spare parts name Travel reduction gear Equipment Model SH200 CX210 Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Parts Diagram

..160142A1
REDUCER SUM TRANSMISSION ASSEMBLY - without track drive motor, Includes: Ref. 1 - 6
. .160146A1
GEAR WHEEL SUM CARRIER ASSEMBLY A - planetary gear; Incl Ref 1 - 6
1.160094A1
GEAR WHEEL SUM CARRIER A - planetary gears
2.160004A1
SUN GEAR SUM GEAR - planetary
3.160278A1
BEARING, NEEDLE,30mm ID x 40mm OD x 19.8mm W SUM NEEDLE - bearing
4.160029A1
LARGE PIN SUM SHAFT - gear
5.160291A1
THRUST WASHER SUM WASHER - thrust
6.160109A1
PIN, ROLL SUM PIN - roll, special
. .160144A1
HOLDER SUM CARRIER ASSEMBLY B - planetary gear, replaces 160144A1, carrier assembly B (replaces 164714A1 ), Includes: Ref. 7 - 12
7.160095A1
GEAR WHEEL SUM CARRIER B - planetary gears
8.160005A1
SUN GEAR SUM GEAR - planetary
9.160273A1
NEEDLE BEARING,35mm ID x 51mm OD x 24.8mm W SUM BEARING - roller
10.160030A1
SHAFT SUM - gear
11.160043A1
THRUST WASHER SUM WASHER - thrust
12.160098A1
PIN, ROLL SUM PIN - roll, special
. .160145A1
GEAR WHEEL SUM CARRIER ASSEMBLY C - planetary gear, Includes: Ref. 13 - 20
13.160207A1
HOLDER SUM CARRIER C - planetary gears
14.160010A1
SUN GEAR SUM GEAR - planetary
15.160326A1
ROLLER SUM NEEDLE - bearing
16.160031A1
SHAFT SUM - gear
17.160037A1
BUSHING SUM RACE - bearing
18.160093A1
COLLAR SUM - needle retaining
19.160044A1
THRUST WASHER SUM WASHER - thrust
20.160099A1
PIN, ROLL SUM PIN - roll, special
21.160007A1
PINION SUM GEAR - drive
22.160038A1
PLATE, THRUST SUM PLATE - thrust
23.160008A1
SUN GEAR SUM GEAR B - sun
24.160009A1
SUN GEAR SUM GEAR C - sun Superseded by part number: 155283A1
25.155643A1
RING, SNAP SUM RING - snap
26.NSS
NOT SOLD SEPARAT CON FLANGE - final drive transmission
27.156144A1
BEARING, BALL,240mm ID x 310mm OD x 32mm W SUM BEARING - ball
28.NSS
NOT SOLD SEPARAT CON HOUSING - bearing
29.160223A1
SHIM KIT SUM KIT - shim
30.160104A1
PIN SUM - dowel
31.863-16090
HEX SOC SCREW,M16 x 90mm, Cl 12.9 SUM BOLT - hex socket, 16-2.0 x 90 mm, class 12.9 Superseded by part number: 2465671
32.863-18055
HEX SOC SCREW,M18 x 55mm, Cl 12.9 SUM BOLT - hex socket, 18-2.5 x 55 mm, class 12.9 Superseded by part number: 108R018Z055N
33.156338A1
PLATE SUM - lock
34.160006A1
PINION SUM GEAR - ring
. .160575A1
SEAL KIT SUM KIT - seal, replaces 160224A1, seal kit, Includes: Ref. 35 and 36
35.155299A1
SEAL SUM - face Superseded by part number: LE01126
36.155183A1
O-RING SUM - seal
37.156200A1
BOLT,M14 x 95mm SUM BOLT - hex socket, 14-2.0 x 95 mm
38.155647A1
COTTER PIN SUM PIN - dowel
39.160220A1
SET OF PARTS SUM KIT - thrust plate
40.160325A1
COVER SUM - final drive transmission
41.863-10020
HEX SOC SCREW,M10 x 20mm, Cl 12.9 CAS BOLT - hex socket, 10-1.5 x 20 mm, class 12.9
42.151033A1
PLUG SUM - hex socket, special
43.151026A1
PLUG SUM - port
44.151022A1
PLUG SUM - hex socket, special
45.892-10016
LOCK WASHER,M16 SUM WASHER - lock, 16 mm
46.155578A1
PIN SUM - dowel
47.160002A1
COUPLING SUM - drive motor Superseded by part number: 155257A1
48.738-1650
LOCK PIN,M6 x 50, Slotted CAS PIN - roll, 6 x 50 mm Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.

Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with KRA1274 160142A1 LNM0389 Final Drive Reduction Gear Used For CX210B 9030B SH200 CX240 SH200 CX210 9030B provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
