Compatible with 9255880 9256990 Excavator Final Drive Used For Hitachi ZX270-3 ZX280-3 ZX280-5G Travel Device

Parts No.: 9255880 9256990 Excavator Model: ZX270-3 Excavator Brand: Hitachi Packing: Wood Box Warranty: 3/6 Months Weight: 300 KG High Light: final drive parts, cat final drive 9255880 9256990 Excavator Final Drive Used For Hitachi ZX270-3 ZX280-3 ZX280-5G Travel Device

Spec Sheet

Excavator spare parts name Travel reduction gear Equipment Model ZX270 280 -3 Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Application

EXCAVATOR ZX250L-5G . ZX270-3 . ZX270-3-HCMC . ZX270-HHE . ZX280-5G . ZX280LC-3 . ZX280LC-3-HCME . ZX280LC-5G . ZX280LCH-3 . ZX280LCN-3FAMS . ZX280LCN-3FHCME . ZX290LC-5B . ZX290LCN-5B . Hitachi

Parts Diagram

ENTIRE GROUP TRAVEL DEVICE:

9255880 I[1] -
TRAVEL DEVICE 9256990 <for assembly of machine> .
9256990[1] -
TRAVEL DEVICE <for transportation> .
00.9255876 I[1] -
MOTOR;OIL (TRAVEL) 9251292 <for assembly of machine> .
00.9251292[1] -
MOTOR;OIL (TRAVEL) <for transportation> .
02.1033048[1] -
DRUM
03.4066695 I[1] -
SEAL;GROUP 4664392
03.4664392[1] -
SEAL;GROUP .
04.4629674[2] -
BRG.;ROL. .
07.A590920[24] -
WASHER;SPRING .
08.J932060[24] -
BOLT .
09.1033227[1] -
SPROCKET .
10.3094717[1] -
NUT
11.4470326[1] -
PLATE;LOCK .
12.J901225[2] -
BOLT .
14.1022198[1] -
CARRIER .
15.4401293[3] -
SPACER
16.3075003[3] -
GEAR;PLANETARY .
17.4455088[6] -
BRG.;NEEDLE .
18.4269470[6] -
PLATE;THRUST .
19.4269452[3] -
PIN .
20.4192021[3] -
PIN;SPRING .
21.3075005[1] -
GEAR;SUN .
23.1022195[1] -
GEAR;RING .
24.J931640[28] -
BOLT .
26.1022197[1] -
CARRIER
27.3075002[3] -
GEAR;PLANETARY .
28.4455099[3] -
BRG.;NEEDLE .
29.4284521[6] -
PLATE;THRUST .
30.4269451[3] -
PIN .
31.4197763[3] -
PIN;SPRING .
32.3074989[1] -
GEAR;SUN .
34.1022196[1] -
CARRIER .
36.3075001[3] -
GEAR;PLANETARY
37.4455098[3] -
BRG.;NEEDLE .
38.4284520[6] -
PLATE;THRUST .
39.4269472[3] -
PIN .
40.4192020[3] -
PIN;SPRING .
41.2048000[1] -
SHAFT;PROP.
43.2045031[1] -
COVER
44.4277474[1] -
PIN;STOPPER .
45.4278168[1] -
BRG.;BALL
46.930451[1] -
RING;RETAINING
48.4245797[3] -
PLUG .
49.4609016 Y[16] -
BOLT;SEMS 4699148 .
49.4699148[16] -
BOLT;SEMS .
51.+++++++[1] -
NAME-PLATE
52.M492564[2] -
SCREW;DRIVE

Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.

Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with 9255880 9256990 Excavator Final Drive Used For Hitachi ZX270-3 ZX280-3 ZX280-5G Travel Device provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
