Compatible with 31N8-10180 31N8-10181 31E9-01052 Excavator Swing Reduction Gear Applied To Hyundai R290-7 R305-7 R300-7

Category: Excavator Swing Drive Gear Parts Parts No.: 31N8-10180 31N8-10181 31E9-01052 Parts NAME: Swing Gearbox Material: Casting, Forged, Steel Warranty: 3/6 Months Package: Standard Export Carton High Light: swing gear box, swing bearing 31N8-10180 31N8-10181 31E9-01052 Excavator Swing Reduction Gear Applied To Hyundai R290-7 R305-7 R300-7

Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.

Spec Sheet

Excavator spare parts name Swing reducer Equipment Model R305-7 R300-7 R290-7 Parts Category excavator swing gear Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Parts DiagramKey Part No Description Qty Serial No - SWING REDUCTION GEAR 1 1~242 - SWING REDUCTION GEAR 1 243~427 - SWING REDUCTION GEAR 1 428~615 - SWING REDUCTION GEAR 1 616~ 1 SHAFT 1 2 COLLAR 1 3 PLATE 1 4 BEARING;TAPER 1 5 CASE;GEAR 1 428~ 5 CASE;GEAR 1 243~427 5 CASE;GEAR 1 1~242 6 PLUG 2 7 SEAL;OIL D90XD65 1 8 BEARING;TAPER 1 9 COLLAR 1 10 PIN 1 11-6 PIN;SPRING 3 11-5 PLATE;THRUST 3 11-4 PLANETARY(NO.2) 3 11-3 BUSH 3 11-2 SHAFT 2 3 11-1 CARRIER(NO.2) 1 11 CARRIER ASS'Y 2 1 12 GEAR;SUN 2 1 13 GEAR;RING 1 14 CARRIER ASS'Y 1 1 14-5 PLATE;THRUST 1 14-4 SHAFT 1 3 14-3 PLANETARY(NO.2) 3 14-1 CARRIER(NO.1) 1 14-2 PLATE;THRUST 3 15 GEAR;SUN 1 1 16 BOLT;SOCKET M12X1.75X95 6 17 PLUG PT3/8 1 18 GASKET 1

* SWING MOTOR ASSY 1 *-2 31E9-01052 SWING REDUCTION GEAR 1 1 XKAQ-00279 CASING-FRONT 1 #0104 1 XKAQ-00329 CASING-FRONT 1 #0105 2 XKAQ-00003 CASING-MIDDLE 1 3 XKAQ-00113 SHAFT-DRIVE 1 #0104 3 XKAQ-00328 SHAFT-DRIVE 1 #0001 4 XKAQ-00006 GEAR-RING 2 1 5 XKAQ-00022 GEAR-PLANET 2 3 6 XKAQ-00012 GEAR-2 SUN 1 7 XKAQ-00008 GEAR-RING 1 1 8 XKAQ-00137 GEAR-PLANET 1 3 9 XKAQ-00061 GEAR-1 SUN 1 10 XKAQ-00016 CARRIER 1 * XKAQ-00021 PIN ASSY NO.2 3 #0001 N11 XKAQ-00060 PIN ASSY-2 3 N32 XKAQ-00046 BUSHING 2 3 12 XKAQ-00059 WASHER-THRUST 6 13 XKAQ-00058 BUTTON-THRUST 1 14 XKAQ-00136 PIN ASSY 1 3 15 XKAQ-00057 PLATE-SIDE 1 3 16 XKAQ-00056 MAGNET 4 17 XKAQ-00055 PLATE-SIDE 3 1 18 XKAQ-00034 BAR-GAUGE 1 19 XKAQ-00035 PIPE-GAUGE 1 20 XKAQ-00111 RING-SPACER 1 21 XKAQ-00053 PIN-KNOCK 2 22 XKAQ-00028 BEARING-ROLLER 1 23 XKAQ-00027 BEARING-ROLLER 1 25 XKAQ-00052 BOLT-SOCKET 16 26 XKAQ-00051 BOLT-SOCKET 12 27 XKAQ-00280 SEAL-OIL 1 #0104 27 XKAQ-00330 SEAL-OIL 1 #0105 28 XKAQ-00050 PIN-SPRING 3 29 XKAQ-00049 PLUG 1 30 XKAQ-00048 PIN-SPRING 3 31 XKAQ-00047 RING-STOP 1 33 XKAQ-00045 RING-STOP 1 34 XKAQ-00292 WASHER-LOCK 1 #0001 35 XKAQ-00013 GEAR-PINION 1 36 XKAQ-00296 PLATE-LOCK 1 #0001 37 XKAQ-00042 BOLT-HEX 2 #0001 38 XKAQ-00041 RING-STOP 3 39 XKAQ-00040 PLATE-SIDE 2 3 40 XKAQ-00109 CIRCLIP 1 41 XKAQ-00110 V-SEAL 1 42 XKAQ-00143 AIR BREATHER ASSY 1 N NOT INDIVIDUALLY SUPPLIED 1

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with 31N8-10180 31N8-10181 31E9-01052 Excavator Swing Reduction Gear Applied To Hyundai R290-7 R305-7 R300-7 provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
