Compatible with 2401P638 Kobelco SK220-3 SK250 K909 Excavator Final Drive Travel Reduction Sun Gear

Product Name: Sun Gear Excavator Model: SK220-3 Parts Number: 2401P638 Warranty: 6 Months Category: Excavator Final Drive Packing: Standard Wooden Box High Light: cat final drive, excavator gearbox

2401P638 Kobelco SK220-3 SK250 K909 Excavator Final Drive Travel Reduction Sun Gear

Spec Sheet

Excavator spare parts name sun gear Equipment Model SK220 SK250 K909 Parts Category excavator final drive Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Application

HEAVY EQUIPMENT K909LC MD240BLC MD240C SK220 SK220LC SK250 SK250LC Kobelco

Parts Diagram

Pos. Part No Qty Parts name Comments . . 24100J11675F4 [1] GEAR REDUCTION UNIT KOB 2 ZD57F30040 [1] SEAL KOB Superseded by part number: ZD58F30040 3 2418J265 [1] HUB HUB 4 2425R210 [2] BALL BEARING KOB 5 ZE82T12000 [2] PLUG KOB 3/4" PT 6 2418P12136 [1] RETAINER KOB 7 ZS23C10030 [38] SCREW,Hex Socket Head, M10 x 30mm KOB M10x1.50x30mm Superseded by part number: ZS28C10030 8 2401N473 [1] RING GEAR KOB 9 ZS23C16085 [18] SCREW,Hex Socket Head, M16 x 85mm KOB M16x2.0x85mm 10 2418P12138 [1] RETAINER KOB 11 ZS23C10025 [18] SCREW,Hex Socket Head, M10 x 25mm KOB M10x1.50x25mm Superseded by part number: ZS28C10025 12 2413J375 [1] SPIDER KOB 13 2401P1298 [3] PINION KOB 14 2401P1300 [1] SUN GEAR KOB 15 2401P1299 [3] PINION KOB 16 2401P638 [1] SUN GEAR KOB 17 2410P793 [3] ROLLER SHAFT KOB 18 2425Z512 [3] NEEDLE BEARING KOB 19 2418T17385 [6] THRUST WASHER KOB 20 ZP26D08032 [3] PIN KOB Roll -- OD 08 x 32mm Long 21 2418T20436 [1] SPACER KOB 22 2413J377 [1] SPIDER KOB 23 2410T355 [3] ROLLER SHAFT KOB 24 2425Z510 [3] NEEDLE BEARING KOB 25 2418T17386 [6] THRUST WASHER KOB 26 ZP26D06032 [3] ROLL PIN KOB 27 2418T20435 [1] SPACER KOB 28 2418P22117 [1] SPACER KOB 29 2414N4248 [1] COVER KOB 30 2420P1518D1 [1] SHIM KOB (1.1) 54 2441U928F2 [1] HYDRAULIC MOTOR KOB
Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.
Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with 2401P638 Kobelco SK220-3 SK250 K909 Excavator Final Drive Travel Reduction Sun Gear provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
