Compatible with 201-26-71190 201-26-71121 201-26-71130 201-26-71140 Komatsu PC60-7 PC75 Excavator Swing Gear Parts

Category: Excavator Swing Drive Gear RING Machine Model: PC60-7 Parts NO.: 201-26-71190 Material: Forged, Steel Warranty: 3-6 Months Package: Standard Export Carton High Light: swing reduction gear, swing bearing 201-26-71190 201-26-71121 201-26-71130 201-26-71140 Komatsu PC60-7 PC75 Excavator Swing Gear Parts

Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing case.

Spec Sheet

Excavator spare parts name Swing reducer Equipment Model PC60 PC75 PC70 Parts Category excavator swing gear Spare parts Condition Brand new MOQ of order(PCS, SET) 1 Parts Availability In stock Delivery Lead time 1-3 days

Parts Diagram

201-26-00130[1]- SWING MACHINERY A. Komatsu ["SN: 59571-UP"] analogs:[] |1. Weight: 64.94 kg.201-26-00060[1]- SWING MACHINERY A. Komatsu China ["SN: 52374-59570"] analogs:[] |1.201-26-00040[1]- SWING MACHINERY A. Komatsu ["SN: 45001-52373"] analogs:[] |1. Weight: 79.01 kg.1.201-26-71113[1]- CASE Komatsu ["SN: 54161-UP"] analogs:[] Weight: 20.5 kg.201-26-71112[1]- CASE Komatsu China ["SN: 52374-54160"] analogs:[] |1.201-26-71111[1]- CASE Komatsu China ["SN: 45001-52373"] analogs:[] |1.2.201-26-71140[1]- SHAFT Komatsu ["SN: 45001-UP"] analogs:[] Weight: 6.18 kg.3.201-26-71261[1]- PLATE Komatsu ["SN: 53993-UP"] analogs:[] Weight: 0.56 kg.201-26-71260[1]- PLATE Komatsu ["SN: 45001-53992"] analogs:["2012671261"] |3. Weight: 0.56 kg.4.201-26-71210[1]- BEARING Komatsu ["SN: 45001-UP"] analogs:[] Weight: 2.073 kg.5.07012-00065[1]- SEAL,OIL Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.062 kg.6.201-26-62320[1]- BEARING Komatsu China ["SN: 45001-UP"] analogs:["890001448"]7.201-26-71250[1]- SPACER Komatsu China ["SN: 45001-UP"] analogs:["890001449"]8.07145-00125[1]- SEAL,OIL Komatsu China ["SN: 45001-UP"] analogs:[] Weight: 0.07 kg.9.07020-00900[1]- FITTING,GREASE Komatsu ["SN: 45001-UP"] analogs:["0700000900", "M012443000109", "R0702000900"] Weight: 0.01 kg.10.21W-26-41310[1]- PIPE Komatsu China ["SN: 59571-UP"] analogs:[]201-26-62420[1]- PIPE Komatsu China ["SN: 45001-59570"] analogs:["890001452"] |10.11.07042-30312[1]- PLUG Komatsu China ["SN: 45001-UP"] analogs:["890001453", "0704220312"]12.07029-00000[1]- VALVE Komatsu ["SN: 45001-UP"] analogs:["6127613890"] Weight: 0.09 kg.13.07042-00415[1]- PLUG Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.056 kg.14.201-26-71130[1]- CARRIER Komatsu ["SN: 45001-UP"] analogs:[] Weight: 1.61 kg.15.201-26-71230[3]- SHAFT Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.27 kg.16.20S-26-71250[3]- PIN Komatsu China ["SN: 45001-UP"] analogs:["890001458"]17.201-26-71180[3]- GEAR Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.54 kg.18.201-26-71290[3]- BEARING Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.1 kg.19.201-26-71270[6]- WASHER,THRUST Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.011 kg.20.04064-02512[3]- RING,SNAP Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.002 kg.21.201-26-71240[1]- WASHER,THRUST Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.32 kg.22.201-26-71121[1]- CARRIER Komatsu ["SN: 52374-UP"] analogs:[] Weight: 0.65 kg.201-26-71120[1]- CARRIER Komatsu China ["SN: 45001-52373"] analogs:[] |22.23.201-26-71220[3]- SHAFT Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.12 kg.25.201-26-71160[3]- GEAR Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.15 kg.26.424-15-12580[3]- BEARING Komatsu China ["SN: 45001-UP"] analogs:["890001468"]30.201-26-71150[1]- GEAR Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.19 kg.31.201-26-71171[1]- GEAR Komatsu ["SN: 52374-UP"] analogs:["2012671170"] Weight: 0.45 kg.201-26-71170[1]- GEAR Komatsu ["SN: 45001-52373"] analogs:["2012671171"] |31. Weight: 0.45 kg.32.201-26-71190[1]- GEAR,RING Komatsu ["SN: 45001-UP"] analogs:[] Weight: 6.6 kg.33.07049-01620[2]- PLUG Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.002 kg.34.07049-02025[4]- PLUG Komatsu ["SN: 54161-UP"] analogs:[] Weight: 0.002 kg.35.04020-01638[2]- PIN Komatsu ["SN: 45001-UP"] analogs:[] Weight: 0.064 kg. This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with 201-26-71190 201-26-71121 201-26-71130 201-26-71140 Komatsu PC60-7 PC75 Excavator Swing Gear Parts provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
