Category: Excavator Drive Gear Parts Excavator Model: EX200-5
Hitachi Parts No.: 1019147 2034836 2034835 2034834 Material: Forged Iron, Steel Warranty: 3 Months Package: Standard Export Carton High Light: final drive parts, cat final drive Travel Device Carrier 1019147 2034836 2034835 2034834 Apply To Hitachi EX200-5 Excavator
Spec Sheet
PARTS NAME EX200-5 Track carrier EQUIPMENT EX200-5 Excavator CATEGORY Excavator track drive ITEM CONDITION New APPLICATION Replacement MATERIAL Steel PROCESSING Casting MOQ 1 pcs
Parts Diagram
ENTIRE GROUP TRAVEL DEVICE:
00-48.(9132405)[2] -
TRAVEL DEVICE ASS'Y (for transportation)
00-48.9119377 I[2] -
TRAVEL DEVICE ASS'Y 9132405 (for assembly of machine)
00.(9131678)[1] -
MOTOR;OIL (for transportation)
00.9120000 I[1] -
MOTOR;OIL 9131678 (for assembly of machine)
02.4114753[1] -
SEAL;GROUP
03.4246793[2] -
BRG.;ROL.
04.1018736[1] -
DRUM
05.1018740[1] -
SPROCKET
06.J932055[16] -
BOLT
07.A590920[16] -
WASHER;SPRING
08.3047448[1] -
HUB
09.3057125[1] -
NUT
10.4246783[1] -
PIN;KNOCK
12.1019147[1] -
CARRIER
13.3063957[3] -
GEAR;PLANETARY
14.4317122[6] -
BRG.;NEEDLE
15.4284521[6] -
PLATE;THRUST
16.4315838[3] -
PIN
17.4116309[3] -
PIN;SPRING
18.3063959[1] -
GEAR;SUN
20.1018789[1] -
GEAR;RING
21.J931640[24] -
BOLT
23.2034836[1] -
CARRIER
24.4192979[2] -
SPACER
25.3063956[3] -
GEAR;PLANETARY
26.4317121[3] -
BRG.;NEEDLE
27.4210851[6] -
PLATE;THRUST
28.4309995[3] -
PIN
29.4192020[3] -
PIN;SPRING
30.3063958[1] -
GEAR;SUN
32.2034835[1] -
CARRIER
33.3063955[3] -
GEAR;PLANETARY
34.4317120[3] -
BRG.;NEEDLE
35.4192910[6] -
PLATE;THRUST
36.4210853[3] -
PIN
37.4173093[3] -
PIN;SPRING
38.2034834[1] -
SHAFT;PROP.
40.2034833[1] -
COVER
41.4285323[1] -
PIN;STOPPER
42.J011230[12] -
BOLT;SEMS
43.4245797[3] -
PLUG
47.M492564[2] -
SCREW;DRIVE
48.3053559[1] -
NAME-PLATE
132.4248607[28] -
BOLT
133.4018545[28] -
WASHER
Description
The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.
Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.
This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Works well with Hitachi EX200-5 Excavator - 1019147 2034836 2034835 2034834 Travel Device Carrier provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
