Compatible with 1014516 2028797 1016125 Planet Carrier Applied To Hitachi EX120-5 Excavator Final Drive Parts

Category: Excavator Track Drive Gear Parts Excavator Model: EX120-5 Hitachi Parts No.: 1014516 2028797 1016125 1016124 2028798 Material: Forged Iron, Steel Warranty: 3/6 Months Package: Standard Export Carton High Light: final drive parts, cat final drive Travel Device Planetary Gear Carrier 1014516 2028797 1016125 1016124 2028798 Used For Hitachi EX120-5 Gear

Description

The Final Drive reducer gearbox is the last component in the Power Train with undercarriage drive system, producing the final speed reduction and torque increase.

Attributes: Heavy Duty Final Drives are designed to be rebuilt and reused.The belowing following gear components are included in the final drive: sun gear, planetary gear, carrier, ring gear, hub, motor housing, needle bearing, roller bearing, seal.

Spec Sheet

PARTS NAME EX120-5 Track carrier EQUIPMENT EX120-5 Excavator CATEGORY Excavator track drive ITEM CONDITION New APPLICATION Replacement MATERIAL Steel PROCESSING Casting MOQ 1 pcs

Application

CHR70 . EX120-2 . EX120-3 . EX120-3C . EX120-5 . EX120-5 JPN . EX120-5HG . EX120-5LV JPN . EX120-5X . EX120-5Z . EX120K-2 . EX120K-3 . EX120SS-5 . EX130H-5 . EX130H-5 JPN . EX130K-5 . EX135UR . HC1110 . HR1200S-5 . HR320G-5 . HR900S-5 . HR900SM . SR-G2000 . SR-P1200 . Hitachi

Parts Diagram

ENTIRE GROUP TRAVEL DEVICE:

00-42.9091652[2] -
TRAVEL DEVICE ASS'Y
00-42.9116399[2] -
TRAVEL DEVICE ASS'Y .
00-42.9116400[2] -
TRAVEL DEVICE ASS'Y .
00-42.9116401[2] -
TRAVEL DEVICE ASS'Y
00.9096731[1] -
MOTOR;OIL
00.9116375[1] -
MOTOR;OIL
00.9116379[1] -
MOTOR;OIL
00.9116383[1] -
MOTOR;OIL
02.4110369[1] -
SEAL;GROUP
03.4228851 Y[2] -
BRG.;ROL. 4321887
03.4321887[2] -
BRG.;ROL.
05.1010325[1] -
SPROCKET
06.J931640[16] -
BOLT
09.4148012[1] -
PIN;KNOCK
11.1014516[1] -
CARRIER
12.3049926[3] -
GEAR;PLANETARY
13.4115435[6] -
BRG.;NEEDLE
14.4245966[3] -
PIN
15.4144020[3] -
PIN;SPRING
16.3043237[1] -
GEAR;SUN
17.4192982[12] -
PLATE;THRUST
18.2028797[1] -
CARRIER
19.4252721[1] -
SPACER
20.3049925[3] -
GEAR;PLANETARY
21.4252658[3] -
BRG.;NEEDLE
22.4178203[3] -
PIN
23.4192020[3] -
PIN;SPRING
24.2028798[1] -
SHAFT;PROP.
25.4258916[1] -
PIN;STOPPER
26.2028800[1] -
COVER
28.J011230[12] -
BOLT;SEMS
30.1016124[1] -
GEAR;RING
31.1016125[1] -
DRUM
32.4269322[1] -
O-RING
33.J931660[16] -
BOLT
34.4245797[3] -
PLUG
35.3053559[1] -
NAME-PLATE
36.M492564[2] -
SCREW;DRIVE
39.3057124[1] -
NUT
42.3059034[1] -
HUB
132.4272305[28] -
BOLT
134.J222016[28] -
WASHER

This product is meticulously designed to ensure exceptional performance and durability, making it an ideal choice for various industrial and engineering applications. Specifically engineered for maximum efficiency, Compatible with 1014516 2028797 1016125 Planet Carrier Applied To Hitachi EX120-5 Excavator Final Drive Parts provides unparalleled performance in challenging environments. Its robust construction ensures durability, while its design meets the diverse needs of industrial and engineering tasks. Whether for maintenance, repair, or upgrades, this product guarantees superior functionality and reliability. An excellent choice for professionals seeking quality and precision.
